water treatment

Backwash filter with pressure reducer

permaster black

Reduce water consumption. And enjoy full comfort.

Filter-pressure reducer combinations of the permaster black series are characterised by all the advantages of the permaster black backwash filters. In addition, the inlet pressure can be reduced and the integrated pressure reducer compensates for pressure fluctuations from the supply network. This effectively protects valves and equipment from damage. Reducing the water pressure to the desired level reduces water consumption without loss of comfort.

  • Protects the drinking water installation from alluvial dirt particles
  • Particularly durable and stable thanks to high-quality materials
  • Light protection against algae formation through tinted filter cup
  • Double cleaning effect for filter sieve and filter cup due to specially developed strip brushes
  • Integrated pressure reducer protects valves and equipment from pressure surges
  • Reduction of water pressure reduces water consumption without loss of comfort
  • Available in connection sizes from DN 25 to DN 50

Protect your installation

Protect your installation

The integrated pressure reducer effectively protects your fittings, valves, devices and the water installation against pressure shocks.

Save water in the process

Save water in the process

Unser Rückspülfilter mit Druckminderer sorgt dafür, dass Sie wertvolles Wasser sparen können.

permaster black Backwash filter with pressure reducer

PT-HWS 25 / 32 effectively protects valves and equipment from damage.

PT-FDK 40/50

For larger systems: Our filter/pressure reducer combination in connection sizes DN 40 and DN 50

Filter water with permaster black.

Filtration.

NORMAL WATER FLOW: In normal operation the water flows from the outside to the inside through the sieve and is filtered.

Patented strip brushes cleaning.

Backwashing.

BACKWASH: The flow direction of the water is reversed. Strip brushes clean the transparent filter cup and the stainless steel filter strainer during backwashing. Dirt particles are rinsed out through the drain funnel.

Technical Information

Detailed Information

Typ

PT-HWS 25

PT-HWS 32

PT-FDK 40

PT-FDK 50

Connection thread d1 DN
customs
25
1
32
40
50
2
Nominal flow rate  in m3/h 3,6 3,6 9,1 14
Mesh size in µm 100 100 100 100
max. operating pressure in bar 16 16 16 16
Control range of the pressure min. in bar 1 - 6 1 - 6 1,5 - 6 1,5 - 6
Max. operating temperature in °C 30 30 30 30
vertical and horizontal installation
Dimension b1 in mm 110 164 320 353
Dimension b2 in mm 204 280 436 467
Dimension h1 in mm 358 358 372 372
Abmessung h2 in mm 478 478 520 520
Dimension t in mm 204 204 68 68
Weight in kg 6,3 7,0 7,0 8,4

minimaster spin-on filter

Spin-on filter

minimaster spin-on filter

minimaster spin-on filter

minimaster spin-on filter

minimaster spin-on filter

Spin-on filter

perfect entry-level

First-class materials and mature technology for a long service life and therefore: the obvious favourite for a cost-effective entry into filter technology. Our high-quality spin-on filter protects fittings and drinking water installations against alluvial dirt particles. As the filter head can be used as a universal connection piece, it is always open to upgrade to a Permaster black backwash filter.

Comfortably scalable

Perma-trade’s patented connection technology allows easy transition to the Permaster black backwash filter.

Comfortably scalable

For clean and safe drinking water

Safe filtering: This prevents dirt and rust from entering the house. For safe drinking water for the whole family.

For clean and safe drinking water

permaster black automatik backwash filter pressure reducer combination

Automatic backwash filter with pressure reducer

permaster black automatik backwash filter pressure reducer combination
permaster black automatik backwash filter pressure reducer combination

permaster black automatik backwash filter pressure reducer combination

Automatic backwash filter with pressure reducer

The solution for maximum comfort

Enjoy maximum comfort thanks to clever automatic control. After preset backwashing intervals, our automatic filter with patented brush technology cleans itself automatically. So you benefit from the proven quality of our permaster black backwash filters in combination with modern technology and maximum ease of use. The built-in pressure reducer also effectively protects your drinking water installation from pressure shocks.

Comfortable, automatic backwashing.

permaster black takes care of the backwashing for you according to automatically preset backwashing intervals.

Comfortable, automatic backwashing.

Save water without loss of comfort and protect your drinking water installation.

The integrated pressure reducer compensates for pressure fluctuations
in the drinking water installation. By lowering the
of the operating pressure are used on the one hand for fittings and
devices are protected against possible damage.
On the other hand, water consumption can also be reduced in this way – and
with the same level of comfort.

Save water without loss of comfort and protect your drinking water installation.

permaster black automatic backwash filter

Drinking water filter with automatic backwashing

permaster black automatic backwash filter

permaster black automatik PT-FM 25/32 A

The advantages of a backwash filter paired with highest comfort.

permaster black automatic backwash filter

permaster black automatic backwash filter

Drinking water filter with automatic backwashing

Maximum comfort thanks to clever automatic control.

permaster black automatic offers all the advantages of our permaster black backwash filters plus the additional convenience that manual backwashing is no longer necessary. After preset backwashing intervals, the automatic filter with patented brush technology cleans itself on its own, thus combining proven quality with state-of-the-art technology and maximum ease of use.

Comfortable, automatic backwashing.

permaster black takes care of the backwashing for you according to automatically preset backwashing intervals.

Comfortable, automatic backwashing.

Double cleaning effect for filter screen and filter cup.

The patented strip brushes clean the stainless steel sieve and the filter cup quickly and reliably. It is not necessary to replace the filter element.

Double cleaning effect for filter screen and filter cup.

permaster black corrosion protection filter

permaster black corrosion protection filter against rust water

permaster black corrosion protection filter

Corrosion protection filter permaster black PT-FM 25/32 RW

We recommend the use of our corrosion protection filter permaster black RW for existing signs of corrosion.

permaster black corrosion protection filter

permaster black corrosion protection filter

permaster black corrosion protection filter against rust water

We recommend our special permaster black corrosion protection filters for corrosion symptoms such as acute rust water occurrence. The backwash filter with zinc sacrificial anode in combination with coarse jet regulators, which increase the volume flow, and our permasolvent active corrosion protection package can reduce the occurrence of brown water from the pipe.

May in combination with permasolvent active corrosion protection packages reduce existing rust water

May in combination with permasolvent active corrosion protection packages reduce existing rust water

Combines the classic advantages of a backwash filter with additional effect

Combines the classic advantages of a backwash filter with additional effect

permaster black

High quality manual backwash filters

permaster black

permaster black backwash filter PT-FM 25/ 32

Our drinking water fine filter with comfortable backwash

permaster black

permaster black

High quality manual backwash filters

The permaster black backwash filter effectively prevents the ingress of dirt and – thanks to its optimized design – is now even more comfortable. The new black-tinted filter cup not only impresses with its particularly elegant appearance, but also offers additional protection against light and algae formation. The transparent cup also allows you to see at any time when the filter needs to be backwashed. According to DIN EN 806-5, the filter must be backwashed every six months at the latest. This can be done easily and practically in the blink of an eye. By turning the drain funnel, the patented belt brushes clean the stainless steel filter and the filter cup without interrupting the water supply. There is no need to replace the filter element.

Double cleaning effect for clean drinking water.

Our patented belt brushes simultaneously clean the stainless steel sieve and the filter cup and thus guarantee an optimal result.

Double cleaning effect for clean drinking water.

Optimal protection for your drinking water installation.

Our permaster backwash filter offers effective protection against the infiltration of dirt and thus long-term protection for your installations and equipment.

Optimal protection for your drinking water installation.
